Black & Gold Anodised Aluminium
Silver & Gold Anodised Aluminium
Finish
Weight: 0.6kg
Size and Weight
Power button
Short press to toggle power on / standby
Input buttons
Select inputs
Clock button
Short press to toggle between internal clock /external clock
Front and Rear
Intel®
Altera®
Cyclone® FPGA
Chip
Precision Ultra-Low Phase Noise Femto Clock
Clock
1 x USB
1 x I2S
1 x AES/EBU
1 x Coaxial
1 x 10MHz Clock Input, 50Ω, Square/Sine wave
Digital Inputs
1 x I2S
Digital Outputs
USB
PCM: 44.1kHz - 768kHz
DSD: DSD64 - DSD512
I2S
PCM: 44.1kHz - 768kHz
DSD: DSD64 - DSD512
AES/EBU
PCM: 44.1kHz - 192kHz
DSD: DSD64 via DoP only
Coaxial
PCM: 44.1kHz - 192kHz
DSD: DSD64 via DoP only
Supported Formats
(Input dependent)
15Hz – 80kHz, within ± 0.5 dB
Frequency Response
0.000005%
THD+N
≤ -165 dB
Crosstalk
≥ 145 dB
Signal to Noise Ratio (SNR)
Compact & Modular Design
Precision Ultra-Low Phase Noise Femto Clock
Proprietary FIFO Buffer and Reclocking Technology
Versatile I2S Inputs & Galvanically isolated I²S Outputs
Support External 10MHz Master Clock Input
Features
Front panel
Controls
5VDC / 2A, DC 5.5/2.1 mm female.
Power
Welcome card with Quick Start guide
Harmony μDDC
Power adapter with interchangeable plugs
In the Box
24-month limited warranty.
Warranty
-
Colours vary by configuration and manufacturing process.
-
Size and weight vary by configuration and manufacturing process.
-
The specification was evaluated using an Audio Precision APx Analyzer under PCM192kHz with 1kHz, A-weighted.
-
Check out our warranty policy for more details.
